Benjamin Baker

He was born in Keyford, which is now part of Frome, Somerset in 1840, educated at Cheltenham Grammar School and, at the age of 16, became an apprentice at Messrs Price and Fox at the Neath Abbey Iron Works. After his apprenticeship he spent two years as an assistant to Mr. W.H. Wilson. Later, he became associated with Sir John Fowler in London. He took part in the construction of the Metropolitan Railway (London). He was also a key expert witness in the Tay rail bridge disaster of 1879.  He designed the cylindrical vessel in which Cleopatra’s Needle, now standing on the Thames Embankment, London, was brought over from Egypt to England in 1877-1878.  He obtained an extremely large professional practice, ranging over almost every branch of civil engineering, and was more or less directly concerned with most of the great engineering achievements of his day.

In 1880, he was called as an expert witness to the inquiry into the Tay Rail Bridge disaster. Although he was acting on behalf of Thomas Bouch, the builder of the first railway bridge across the Tay, he performed his role with independence and tenacity. His testimony was against the theory that the bridge was simply blown over by the wind that fateful night. He made a meticulous survey of structures at or near the bridge, and concluded that wind speeds were not excessive on the night of the disaster. The official analysis of the failure suggested that a wind pressure of over 30 pounds per square foot was needed to cause toppling of the structure, but he examined smaller structures in the vicinity of the bridge and concluded that the pressure could not have exceeded 15 pounds per square foot on the night of the disaster. Such smaller structures included walls, ballast on the track on the bridge and both signal boxes either actually on or very near the bridge.

He also said in his statement to the court that he had built over 12 miles (19 km) of railway viaduct, referring to his design of the elevated railroad in New York in 1868, some of which still survives in Manhattan (unused). By this time he had already made himself an authority on bridge construction, and shortly afterwards he was engaged on the work which made his reputation with the general public: the design and erection of the Forth Bridge in collaboration with Sir John Fowler and William Arrol. It was an almost unique design as a large cantilever bridge, and was built entirely in steel, another unprecedented development in bridge engineering. Stiffness was provided by hollow tubes which were riveted together so as to make sound joints. Baker promoted his design in numerous public lectures, and arranged demonstrations of the stability of the cantilever by using his assistants as stage props.

With Sir John Fowler, he designed and engineered the Forth Bridge after the Tay bridge collapse. It was a cantilever bridge and Baker gave numerous lectures on the principles which lay behind his design. Thomas Bouch had originally been awarded the contract but he lost it after the Tay bridge Inquiry reported in June 1880. The bridge was built entirely in steel, much tougher than cast iron. He used hollow steel tubes to create the cantilever, and it was then the largest bridge of its kind in the world. The bridge is, even today, regarded as an engineering marvel. It is 2.5 km (1.6 mi) in length, and the double track is elevated 46 m (approx. 150 ft) above high tide. It consists of two main spans of 1,710 ft (520 m), two side spans of 675 ft, 15 approach spans of 168 ft (51 m), and five of 25 ft (7.6 m).[3] Each main span comprises two 680 ft (210 m) cantilever arms supporting a central 350 ft (110 m) span girder bridge. The three great four-tower cantilever structures are 340 ft (104 m) tall, each 70 ft (21 m) diameter foot resting on a separate foundation. The southern group of foundations had to be constructed as caissons under compressed air, to a depth of 90 ft (27 m). At its peak, approximately 4,600 workers were employed in its construction. Initially, it was recorded that 57 lives were lost; however, after extensive research by local historians, the figure has been revised upwards to 98. Eight men were saved by boats positioned in the river under the working areas. More than 55,000 tons of steel were used, as well as 18,122 m³ of granite and over eight million rivets. The bridge was opened on 4 March 1890 by the Prince of Wales, later King Edward VII, who drove home the last rivet, which was gold plated and suitably inscribed. A contemporary materials analysis of the bridge, c. 2002, found that the steel in the bridge is of good quality, with little variation.

The use of a cantilever in bridge design was not a new idea, but the scale of Baker’s undertaking was a pioneering effort, later followed in different parts of the world. Much of the work done was without precedent, including calculations for incidence of erection stresses, provisions made for reducing future maintenance costs, calculations for wind pressures made evident by the Tay Bridge disaster, the effect of temperature stresses on the structure, and so on.  Where possible, the bridge used natural features such as Inchgarvie, an island, the promontories on either side of the firth at this point, and also the high banks on either side. The remains of Thomas Bouch’s first attempts at his bridge can also be seen on the island.

The bridge has a speed limit of 50 mph (80 km/h) for passenger trains and 20 mph (32 km/h) for freight trains. The weight limit for any train on the bridge is 1,422 tonnes (1,442,000 kg) although this is waived for the frequent coal trains, provided two such trains do not simultaneously occupy the bridge. The route availability code is RA8, meaning any current UK locomotive can use the bridge, which was designed to accommodate heavier steam locomotives. Up to 190–200 trains per day crossed the bridge in 2006. A structure like the Forth Bridge needs constant maintenance and the ancillary works for the bridge included not only a maintenance workshop and yard but a railway “colony” of some fifty houses at Dalmeny Station.

“Painting the Forth Bridge” is a colloquial term for a never-ending task (a modern rendering of the myth of Sisyphus), coined on the erroneous belief that, at one time in the history of the bridge, repainting was required and commenced immediately upon completion of the previous repaint. According to a 2004 New Civil Engineer report on contemporary maintenance, such a practice never existed, although under British Rail management, and before, the bridge had a permanent maintenance crew.

A contemporary repainting of the bridge commenced with a contract award in 2002, for a schedule of work expected to continue until March 2009, involving the application of 20,000 m² of paint at an estimated cost of £13M a year. This new coat of paint is expected to have a life of at least 25 years. In 2008 the total cost was revised upwards to £180M, and projections for finishing the job to 2012.In a report produced by JE Jacobs, Grant Thornton and Faber Maunsell in 2007 which reviewed the alternative options for a second road crossing, it was stated that the estimated working life of the Forth Bridge was in excess of 100 years.

On the completion of this undertaking in 1890 he was appointed Knight Commander of the Order of St Michael and St George (KCMG), and in the same year the Royal Society recognized his scientific attainments by electing him one of its fellows. In 1892 the French Academy of Sciences recognized the work of Fowler and Baker by the joint award of the Poncelet Prize; Baker received 2000 francs because the prize money was doubled. Ten years later at the formal opening of the first Aswan Dam, for which he was consulting engineer, he was appointed Knight Commander of the Order of the Bath (KCB). He served as president of the Institution of Civil Engineers between May 1895 and June 1896. He was elected a Foreign Honorary Member of the American Academy of Arts and Sciences in 1899.

Baker also played a large part in the introduction of the system widely adopted in London of constructing underground railways in deep tubular tunnels built up of cast iron segments. He was also involved in an unsuccessful scheme in 1899 proposed by the North West London Railway to build a tube line in north-west London.  Baker was also the author of many papers on engineering subjects. In 1872 Baker wrote a series of articles titled, “The Strength of Brickwork.” In these articles Baker argued that the tensile strength of cement should not be neglected in calculating the strength of brickwork. He wrote that if the cement was neglected then several structures of his time should have collapsed.  He died at Pangbourne, Berkshire where he lived in his later years and was buried in the village of Idbury in Oxfordshire.

More Images

  • Benjamin 1 -

  • Benjamin 2 -

Born

  • March, 31, 1840
  • Frome, United Kingdom

Died

  • May, 19, 1907
  • Pangbourne, United Kingdom

Cemetery

  • St Nicholas Churchyard
  • Oxfordshire, England
